SF300 IP Based Fingerprint Access Control & Time Attendance
- The SF300 is an IP based fingerprint terminal, which operate in both network mode and standalone mode. it can connect with ZKAccess3.5 software for access control and time attendance management.
- Wiegand output makes SF300 flexible to connect with ZKTeco or any 3rd party controllers as a slave reader, Additionally, wiegand input allows two units of SF300 to configure with each other and utilize Master & Slave solution, which requires user verification at both entrance and exit. Meanwhile, anti-passback function can be used to maximize the security.
- Auxiliary input interface allows SF300 to connect with an external source, for instance, a smoke detector or emergency switch. Once the linkage function is enabled through the machine menu, the device would generate an alarm signal and open the door in case of emergency.
Specification
| ZKTeco SF300 IP Fingerprint Access Control System | |
|---|---|
| Access Control Interface | Electric lock, Door sensor, Alarm, Exit button, Door Bell |
| Algorithm Version | ZKFinger VX10.0 |
| Aux. Input | 1ea for linkage function |
| Card Capacity (Optional) | 5,000 (EM/IC Card) |
| Communication | TCP/IP, USB Host |
| Dimension(L x W x H) | 105 x 105 x 34mm |
| Fingerprint Capacity | 1,500 |
| Fingerprint Sensor | ZK Optical Sensor (500DPI) |
| LCD | 2.8 inch resistive touch screen |
| Model | SF300 |
| Operating Humidity | 20 ~ 80% |
| Power Supply | DC 12V/3A |
| Records Capacity | 80,000 |
| Wiegand Signal | Wiegand input & output |
ZKTeco F22 Fingerprint Time Attendance
- Ultra Slim Fingerprint Time Attendance & Access Control Terminal
- 2.4 Inch TFT LCD Colour Screen
- 3000 FP Templates, 30K Transactions Capacity, 5000 Cards
- BioID Sensor; RS232/485, TCP/IP, USB-host, Wi-Fi
- Wiegand Signal: Input & Output. Optional ADMS firmware
- Auxiliary input for linkage function
- Software bundled ZKTime.Net 3.0 (Free License for 5 devices or 100User)
- BioTIme7.0 (license) @ Optional ADMS firmware
Specification
| ZKTeco F22 Fingerprint Time Attendance | |
|---|---|
| Display | 2.4-inch TFT LCD Color Screen |
| Fingerprint Capacity | 3000 |
| Card Capacity | 5000(Optional) ID or mifare card |
| Transaction Capacity | 30,000 |
| Sensor | BioID Sensor/ SilkID Sensor (optional) |
| Algorithm Version | ZKFinger VX10.0 |
| Communication | RS232/485, TCP/IP, USB-host,Wi-Fi |
| Access Control Interface | 3rd Party Electric Lock, Door Sensor, Exit Button, Alarm Wiegand Signal Input, Output |
| Aux. Input | 1ea for linkage function |
| Functions | DST, Automatic Status Switch, Record query, T9 input, 14 digit user ID, Anti-passback, Scheduled-Bell, Printer(Optional), ADMS(Optional) |
| Power Supply | 12V DC,3A |
| Operating Humidity | 20%-80% |
| Dimension(LxWxH) | 158.5×78.0x19.4mm |
| SDK and software | Standalone SDK,ZKAccess3.5 software |
ZKTeco TF1700 Access Control
- 1.54′;OLED Screen
- IP65 Waterproof and dustproof
- Fingerprint and Rfid Identification
- Fingerprint Capacity :3000
- ID Card Capacity 10,000
- Log Capacity :30,000
- Communication :TCP/IP ,RS485,USB Host
- Access Control Interface for electrick Lock ,door sensor ,alarm ,Exit Button and Door Bell
- Wiegand input & Output
- Optional 8000 FP(Pull SDK Firmware)
- Software bundled ZKTime.Net 3.0 (Free License for 5 devices or 100User)
Specification
| ZKTeco TF1700 Access Control | |
|---|---|
| Fingerprint Sensor | Infrared detection fingerprint sensor |
| Algorithm Version | ZK Finger 10.0 |
| Communication | TCP/IP, RS485, USB Host |
| Fingerprint Capacity | 3,000 Fingerprints(8,000 Optional) |
| Card Capacity | 30,000 Cards |
| Log Capacity | 100,000 Transactions |
| RF Card | EM(standard)/Mifare(optional) |
| Authentication Finger/PIN/Card | |
| Wiegand | Signal Wiegand input&output |
| Ingress Protection Rate | IP65 |
| Display | 128 x 64 OLED |
| Keypad | 3 x 5 keypads & doorbell |
| Sound and Interface | Buzzer and multi-color LED |
| Operating Voltage | 12VDC 3A |
ZKTeco F18 Fingerprint Access Control System
- Fingerprint with built-in RFID or Mifare Reader; TFT LCD Screen
- Stores 1,500 fingerprint templates, 5,000 cards and 30,000 transactions
- Reads Fingerprint and/or RFID or Mifare Card (optional). Supports PIN access
- Wiegand Signal: Input & Output. Optional ADMS firmware
- 12VDC Powered; Software bundled ZKAccess 3.5 (Supports Max 50 devices)
- Wiegand Signal: Input & Output
- Software bundled ZKTime.Net 3.0 (Free License for 5 devices or 100User)
- BioTIme7.0 (license) @ Optional ADMS firmware
Specification
| ZKTeco F18 Fingerprint Access Control System | |
|---|---|
| Display 2.4-inch TFT LCD Color Screen | |
| Fingerprint Capacity | 3000 |
| Card Capacity | 5000(Optional) ID /Mifare/HID card |
| Transaction Capacity | 30,000 |
| Sensor | ZK Optical Sensor |
| Algorithm Version | ZK Finger V9.0&10.0 |
| Communication | RS232/485, TCP/IP, USB-host |
| Access Control Interface | 3rd Party Electric Lock, Door Sensor, Exit Button, Alarm, Doorbell |
| Wiegand Signal | Input, Output,SRB |
| Functions | DST, Record Query, Anti-passback, External RS485 fingerprint reader, Printer(Optional) |
| Power Supply | 12V DC, 3A |
| Operating Humidity | 20%-80% |
| SDK and Software | Standalone SDK,ZKAccess3.5 software |
ZKTeco FR1200-MF Fingerprint Reader
FR1200, a fingerprint reader with an RS485 communication interface works with biometric access controllers and fingerprint standalone access control, including inBIO series controllers, F8, and so on. It offers the function of capturing and transferring fingerprint samples to access the control panel. With its IP65 rated rugged structure, FR1200 offers extra durability in all weather conditions including outdoor environments.
- Out Weigand Reader
- Fingerprint Reader with RFID or Mifare Module
- IP65 rated enclosure for outdoor use
- Can be used with inBio, EC10, and also as a slave reader for F18/F21lite/F22
- Communication: RS485
Specification
| ZKTeco FR1200-MF Fingerprint Reader | |
|---|---|
| CPU | 324MHz |
| Standard Function | ID Card Module |
| Working Voltage | 12VDC |
| Size | Height: 102mm; Width: 50mm; Depth: 37mm |
| Sensor | ZK small-sized sensor |
| Optional Function | MF Card Module |
| Communication | RS485 |
| Voice Prompt | Buzzer |
| Protection Grade | IP65 |
ZKBio CV Security Time Attendance Module Web-Based
ZKBio CVSecurity provides a comprehensive web-based security platform with the adoption of hybrid biometric and computer vision technology. It contains multiple modules: Personnel, Time & Attendance, Access Control, Visitor Management, Parking, Elevator Control, FaceKiosk, Video Management, Mask and Temperature Detection, Online/ Offline Consumption, Guard Patrol, Intelligent Video Analytics, Locker Management, Intrusion Alarm, Service Center, and another smart sub-system.
- Package:
- 5 Attendance Points – 30,000 Personnel
- 10 Attendance Points – 30,000 Personnel
- 25 Attendance Points – 30,000 Personnel
- 50 Attendance Points – 30,000 Personnel
- Add-on 1-Time Attendance Point (Available for packages 25-100 points)
- Add-on 5 Time Attendance Point (Available for packages 25-100 points)
Specification
| ZKTeco ZKBio CV Security Time Attendance Module Web-Based | |
|---|---|
| 3rd-Party Integration | 324MHz |
| API | Restful API Supports: Person Interface of Attendance Area RESTful API Person Interface RESTful API Person Biometric Template Interface RESTful API Card Interface RESTful API Department Interface RESTful API Area Interface RESTful API Reader Interface RESTful API Media Interface RESTful API Door Interface RESTful API Floor Interface RESTful API Access Control Interface RESTful API Access Control Device Interface RESTful API Access Level RESTful API Access Control Transaction Interface RESTful API Attendance Transaction Interface RESTful API Attendance Device Interface RESTful API Elevator Control Level Interface RESTful API Elevator Device Interface RESTful API Elevator Transaction Interface RESTful API Vehicle Management Authorization Interface RESTful API Vehicle Management Transaction Interface RESTful API Visitor Reservation Interface RESTful API Visitor Level Interface RESTful API Visitor Registration Check Out Interface RESTful API Temperature Transactions Interface RESTful API FaceKiosk Device Interface RESTful API FaceKiosk Area Interface RESTful AP |
| Certifications | ISO/IEC 27001:2013, ISO/IEC 27701:2019, ISO9001, ISO20000. |
| Client-Side | Windows 7 Pro/Ultimate* SP1, Windows 8.1 Pro/Enterprise, Windows 10 Pro/Enterprise or Windows 2019 Server Windows 11 |
| Cybersecurity | ZK small-sized sensor |
| Data Protection | 256-bit AES encryption |
| Database Mapping | Supports |
| Database Platform | Buzzer |
| GIS Map | Google Map / Baidu Map / SuperMap |
| Intrusion Alarm Integration | Bosch/RISCO |
| Maximum Access Control Level | Unlimited (depending on the performance of the server & network) |
| Maximum Access Controlled Doors | 5,000 |
| Maximum Attendance Points | 2,000 |
| Maximum Controlled Outputs Maximum Inputs | Unlimited (depending on the device’s configuration) |
| Maximum Faces | 300,000 |
| Maximum Fingerprints | 300,000 |
| Maximum Intelligent Video Servers | 50 |
| Maximum Number of ClientsAllowed to Access | Unlimited (depending on the performance of the server & network) |
| Maximum Passwords | 300,000 |
| Maximum RFID Cards | 300,000 |
| Maximum Supported Admin Users | Unlimited (depending on the performance of the server & network) |
| Maximum Supported Personnel | 300,000 |
| Maximum Surveillance Cameras | 1024 |
| Maximum Visitors (Monthly) | 100,000 |
| Microsoft Active Directory | No Version restriction |
| Notification / Messages | Line / WhatsApp / Amazon SNS / SMS |
| Operating System | |
| Server-Side | Windows 7 Pro/ Ultimate** SP1, Windows 2008 Server R2 (64-bit only), Windows 2012 Server, Windows 2012 Server R2, Windows 2016 Server, Windows 8.1 Pro, Windows 10 Pro/Enterprise or Windows 2019 Server Windows 11 |
| Suggested Browser for Client-Side | IE 11 or later, Chrome 33 or later, Safari 6.1.3 or later Edge |
ZKBio CV Security Access Control Module Web-Based Security Platform
ZKBio CVSecurity provides a comprehensive web-based security platform with the adoption of hybrid biometric and computer vision technology. It contains multiple modules: Personnel, Time & Attendance, Access Control, Visitor Management, Parking, Elevator Control, FaceKiosk, Video Management, Mask and Temperature Detection, Online/ Offline Consumption, Guard Patrol, Intelligent Video Analytics, Locker Management, Intrusion Alarm, Service Center, and another smart sub-system.
- Package:
- 10 Attendance Points – 30,000 Personnel
- 25 Attendance Points – 30,000 Personnel
- 50 Attendance Points – 30,000 Personnel
- 75 Attendance Points – 30,000 Personnel
- 100 Attendance Points – 30,000 Personnel
- Add-on 1 door (Available for package 25-100 doors)
- Add-on 5 doors (Available for package 25-100 doors)
Specification
| ZKTeco ZKBio CV Security Access Control Module Web-Based Security Platform | |
|---|---|
| 3rd-Party Integration | |
| API | Restful API Supports: Person Interface of Attendance Area RESTful API Person Interface RESTful API Person Biometric Template Interface RESTful API Card Interface RESTful API Department Interface RESTful API Area Interface RESTful API Reader Interface RESTful API Media Interface RESTful API Door Interface RESTful API Floor Interface RESTful API Access Control Interface RESTful API Access Control Device Interface RESTful API Access Level RESTful API Access Control Transaction Interface RESTful API Attendance Transaction Interface RESTful API Attendance Device Interface RESTful API Elevator Control Level Interface RESTful API Elevator Device Interface RESTful API Elevator Transaction Interface RESTful API Vehicle Management Authorization Interface RESTful API Vehicle Management Transaction Interface RESTful API Visitor Reservation Interface RESTful API Visitor Level Interface RESTful API Visitor Registration Check Out Interface RESTful API Temperature Transactions Interface RESTful API FaceKiosk Device Interface RESTful API FaceKiosk Area Interface RESTful AP |
| Certifications | ISO/IEC 27001:2013, ISO/IEC 27701:2019, ISO9001, ISO20000. |
| Client-Side | Windows 7 Pro/Ultimate* SP1, Windows 8.1 Pro/Enterprise, Windows 10 Pro/Enterprise or Windows 2019 Server Windows 11 |
| Cybersecurity | |
| Data Protection | 256-bit AES encryption |
| Database Mapping | Supports |
| Database Platform | |
| GIS Map | Google Map / Baidu Map / SuperMap |
| Intrusion Alarm Integration | Bosch/RISCO |
| Maximum Access Control Level | Unlimited (depending on the performance of the server & network) |
| Maximum Access Controlled Doors | 5,000 |
| Maximum Attendance Points | 2,000 |
| Maximum Controlled Outputs Maximum Inputs | Unlimited (depending on the device’s configuration) |
| Maximum Faces | 300,000 |
| Maximum Fingerprints | 300,000 |
| Maximum Intelligent Video Servers | 50 |
| Maximum Number of ClientsAllowed to Access | Unlimited (depending on the performance of the server & network) |
| Maximum Passwords | 300,000 |
| Maximum RFID Cards | 300,000 |
| Maximum Supported Admin Users | Unlimited (depending on the performance of the server & network) |
| Maximum Supported Personnel | 300,000 |
| Maximum Surveillance Cameras | 1024 |
| Maximum Visitors (Monthly) | 100,000 |
| Microsoft Active Directory | No Version restriction |
| Notification / Messages | Line / WhatsApp / Amazon SNS / SMS |
| Operating System | |
| Server-Side | Windows 7 Pro/ Ultimate** SP1, Windows 2008 Server R2 (64-bit only), Windows 2012 Server, Windows 2012 Server R2, Windows 2016 Server, Windows 8.1 Pro, Windows 10 Pro/Enterprise or Windows 2019 Server Windows 11 |
| Suggested Browser for Client-Side | IE 11 or later, Chrome 33 or later, Safari 6.1.3 or later Edge |
ZKBio CV Security Access Control Module (V5000 All-in-One Biometric Security Software)
- ZKBio Security V5000 All-in-one 11 modules and sub-systems, flexible for all sizes projects and various industries
- Standard Access Control features and professional advanced access control functions (Global Anti-Passback, Global Linkage, Global Interlock, etc.)
- Updated intelligent video global linkage function that allows users to configure smart video camera events such as Motion Detection, Cross Line Alarm, Human Detection, Blocklist/ Stranger Alarm, to trigger intelligent linkage actions, including Video Capture, Video Recording, Access Control (Door Opening, Closing, Lockdown, Unlocking), Elevator Control (Floor Button Release, Locking), Email Alert/ Notification, Text Message Alert/ Notification. This truly realizes secure supervisory control and management
- Professional Video Management features such as real-time preview, video playback, linkage alarm, decoding video, monitoring by face images and alert for suspicious individuals, alarm linkage, providing multiple functionalities for various applications.
- Advanced Visitor Management module, improving the professionalism of the enrollment process and visitor check-in. It
streamlines the enrollment with pre-registration or self-registration options, and allows users to create watch lists and screen against unwanted visitors - Based on some advanced biometric technology, supporting the latest Body Temperature & Mask Detection Terminals, the ZKBioSecurity platform provides responsive, intuitive, user-friendly web application and various analysis reports to assist in screening body temperature in secure areas with high eficiency in a multiple of scenarios
- Multiple languages supported: English, Spanish, Simplified Chinese, Traditional Chinese, Russian, Indonesian, Thai, Vietnamese, Korean, Portuguese, French, Arabic.
- Standard third-party interface, with strong platform expansion capability
Specification
| ZKTeco ZKBio Security V5000 | |
|---|---|
| Current Version | V5000 3.0.0 |
| Database | PostgreSQL (Default), MS SQL Server, Oracle (Optional) |
| Door Capacity | 2,000 |
| Suggested | Browsers IE 11+/ Firefox 27+/ Chrome 33+ |
| Supported OS | Windows 7/ 8/ 8.1/ 10 server 2008/ 2012/ 2016/ 2019 |
| User Capacity | 30,000 |
ZKBioAccess (Web-Based CIS Structure) – Access Control only for C3 & inBio
ZKBio Access IVS is a lite web-based security platform developed by ZKTeco, which supports most ZKTeco Hardware. It provides abundant functionality that fulfills management requirements of small- to medium-sized businesses: Personnel Management, Access Control, Attendance Management, Video Surveillance, Temperature Detection and Management, System Management.
- Target market: SMB Charged (Channel Distribution)
- Protocol: Push SDK & Pull SDK
- Database: PostgreSQL
- Service policy: 1 year free warranty
Specification
| ZKBioAccess (Web-Based CIS Structure) – Access Control only for C3 & inBio | |
|---|---|
| Standalone Access Control Devices with PUSH Firmware (F18-S/ F19-S/ F21 Lite/ MB800/ etc.) | |
| Visible Light Facial Recognition Series Devices | |
| Visible Light Face Recognition Series Device | |
| MS SQL Server & Oracle (Optional) | |
| Access Control Device | Access Control Panels (C3 Series/ inBio Series) |
| Attendance Device | New Platform Push Attendance Device (IN01-A/ U160-C/ iClock580/ uFace102/ etc.) |
| Database | PostgreSQL (Default) |
| License Control | Support (Provide Free Standard License on O cial Website |
| License Fee | Contact us for Pricing |
| Multiple Admin Loginl | Support |
| Protocol | Push SDK & Pull SDK |
| Service Policy | 1 Year Free Warranty |
| VMS (Video Management System) | Support |
ZKBioTime 8.0 Time Attendance System (Management Software)
License Validity: 10 years. Pre-requisite for Biotime: ADMS on device. Require UPK. 2 Devices, 2000 Personnel, 1 Mobile APP
- Lite – 10 Devices ;2000 User
- Standard – 20 Devices ;User
- Premium – 50 Devices ; 10,000 User
- Mobile APP – 5 user package
- Mobile APP – 10 user package
- ADMS license per device (Required to buy when use ZKBiotime 7.0)
Specification
| ZKTECO 8.0 BioTime Time Attendance System (Management Software) | |
|---|---|
| CPU | Dual Core Processor with speeds of 2.4 GHz or faster |
| Database | PostgreSQL (Default) / MSSQL Server 2005/2008/2012/2014 / MySQL5.0.54/ Oracle 10g/11g/12c |
| Device Capacity | 500 devices in a single server |
| Hardware | |
| Monitor Resolution | 1024 * 768 or above |
| RAM | 4GB RAM or above |
| Software | |
| Storage | Available space of 100GB or above. (We recommend using NTFS hard disk partition as the software installation directory.) |
| Suggested Browsers | Chrome 33+ / IE 11+ / Firefox 27+ |
| Supported Devices | Standalone Device with Attendance PUSH Protocol:Green Label Series/ A Series/ B Series/ FaceKiosk Series/ iClock Series/ IN Series/ KF Series/ MB Series/P Series/ S Series/ Silk Series/ T Series/ U Series/ UA Series/ uFace Series/ VF Series/ X Series |
| Supported OS | (64-bit only) Windows 7/8/8.1/10 / Server 2003/2008/2012/2014/2016 |
| System Architecture | Server / Browser |
ZKTime.Net 3.0 Time & Space Synchronized
- 5 Devices, 100 Personnel (10 years)
- 5 Doors, 2000 User (10 years)
- 50 Devices, 500 User (3 years)
- 50 Devices, 2000 User (3 years)
Specification
| ZKTime.Net 3.0 Time & Space Synchronized | |
|---|---|
| Item | Description |
| Temples | Fingerprints / RFID / Face |
| Devices | TFT / B&W / iClock Series / IN Series / iFace Series Standalone Access Control devices / MT100 |
| Networking | TCP/IP / Wireless |
| OS | Windows XP/Vista/7/8 32Bit & 64Bit |
| Database | SQL Lite(default) / SQL Server / PostgreSQL / MySQL Etc. |
| Max Capacity | 2000 Users, 50 Devices |
| Multi-languages | English/Traditional Chinese/Arabic Spanish/French/Japanese/Russian/Turkish/Vietnamese |
